A company wants to migrate its SAP landscape from on premises to AWS
What are the MINIMUM requirements that the company must meet to ensure full support of SAP on AWS? (Select THREE.)
Answer : C, D, F
C is correct because installing, configuring and running the AWS Data Provider for SAP on each instance in the landscape is required to provide specific performance metrics that are needed by SAP support. D is correct because protecting all production instances by using Amazon EC2 automatic recovery is required to ensure high availability and fault tolerance for SAP systems. F is correct because deploying the SAP landscape on an AWS account that has either an AWS Business Support plan or an AWS Enterprise Support plan is required to ensure full support of SAP on AWS. The other options are not relevant or necessary for ensuring full support of SAP on AWS. Reference: https://docs.aws.amazon.com/whitepapers/latest/sap-on-aws-technical-deployment-guide/security.html https://docs.aws.amazon.com/whitepapers/latest/sap-on-aws-technical-deployment-guide/high-availability.html https://docs.aws.amazon.com/whitepapers/latest/sap-on-aws-technical-deployment-guide/support.html
A company is planning to move to AWS. The company wants to set up sandbox and test environments on AWS to perform proofs of concept (POCs) Development and production environments will remain on premises until the POCs are completed.
At the company's on-premises location SAProuter is installed on the same server as SAP Solution Manager. The company uses SAP Solution Manager to monitor the entire landscape The company uses SAP router to connect to SAP Support The on-premises SAP Solution Manager instance must monitor the performance and server metrics of the newly created POC systems on AWS. The existing SAP router must be able to report any issues to SAP
What should an SAP solutions architect do to set up this hybrid infrastructure MOST cost-effectively'?
Answer : C
It allows to use the existing on-premises SAP Solution Manager and SAP router instances to monitor and report issues from the POC systems on AWS, thus minimizing the additional infrastructure costs. Also this approach allows to use the VPN to establish a secure connection between the on-premises network and the AWS environment, thus ensuring that the monitoring data is transmitted securely. Option D can also be used to manage the transport of the customizing objects and support packages between the on-premises systems and the POC systems on AWS.
https://docs.aws.amazon.com/sap/latest/general/overview-sap-planning.html#figure-4
A company wants to migrate its SAP workloads to AWS from another cloud provider. The company's landscape consists of SAP S 4HANA SAP BWMHANA SAP Solution Manager and SAP Web Dispatcher SAP Solution Manager 15 running on SAP NANA
The company wants 10 change the operating system from SUSE Linux Enterprise Server to Red Hat Enterprise Linux as a pan of this migration. The company needs a solution that results in the least possible downtime for the SAP SMHANA and SAP BW 4HANA systems.
Which migration solution will meet these requirements?
Answer : D
This solution uses SAP HANA system replication to replicate the data between the source system and the target AWS system for SAP S/4HANA and SAP BW/4HANA. This will minimize the downtime as the data is replicated in real-time, and once the replication is completed, the company can switch over to the target system with minimal disruption to the business. Additionally, this solution uses SAP Software Provisioning Manager to perform a system export/import for SAP Solution Manager. This will allow the company to migrate the system settings and configurations from the source system to the target system, reducing the time and effort required to reconfigure the system after the migration. Finally, the company can reinstall SAP Web Dispatcher on AWS with the necessary configuration and change the operating system from SUSE Linux Enterprise Server to Red Hat Enterprise Linux.
A company has moved an of its SAP workloads to AWS During peak business hours end users are reporting performance issues because work processes are going into PRIV mode on an SAP S/4HANA system An SAP support engineer indicates that SAP cannot provide support for this issue because some specific performance metrics are not available.
Which combination of actions must the company perform to comply with SAP support requirements? (Select THREE.)
Answer : C, D, F
https://docs.aws.amazon.com/whitepapers/latest/sap-on-aws-technical-deployment-guide/security.html https://docs.aws.amazon.com/whitepapers/latest/sap-on-aws-technical-deployment-guide/sap-monitoring.html
A company is using a multi-account strategy for SAP HANA and SAP BW 4HANA instances across development QA and production systems m the same AWS Region Each system is hosted m its own VPC The company needs to establish cross-VPC communication between the SAP systems.
The company might add more SAP systems m the future. The company must create connectivity across the SAP systems and hundreds of AWS accounts. The solution must maximize scalability and reliability.
Which solution will meet these requirements?
Answer : A
Create an AWS Transit Gateway in a central networking account and attach the transit gateway to the AWS accounts. This solution will meet the requirements as it will maximize scalability and reliability and provide connectivity between the SAP systems and hundreds of AWS accounts. Additionally, as more SAP systems might be added in the future, this solution will also be able to handle the increased load.
A company is migrating its SAP workloads to AWS The company's IT team installs a highly available SAP S.4HANA system that uses the SAP HANA system replication cluster package on SUSE Linux Enterprise Server. The IT team deploys the system by using cluster nodes m different Availability Zones within the same AWS Region.
After the initial launch of the SAP application the application is accessible However after failover the IT team cannot access the application even though the system is up and running on the secondary node After investigation an SAP solutions architect discovers that the virtual IP address has not been used correctly
Which combination of steps should the SAP solutions architect take to resolve this problem? (Select TWO.)
Answer : C, E
A company has deployed a highly available SAP NetWeaver system on SAP HANA into a VPC The system is distributed across multiple Availability Zones within a single AWS Region SAP NetWeaver is running on SUSE Linux Enterprise Server for SAP SUSE Linux Enterprise High Availability Extension is configured to protect SAP ASCS and ERS instances and uses the overlay IP address concept The SAP shared dies sapmnt and . usrsap. trans are hosted on an Amazon Elastic File System (Amazon EFS) tile system
The company needs a solution that uses already-existing private connectivity to the VPC. The SAP NetWeaver system must be accessible through the SAP GUI client tool.
Which solutions will meet these requirements? (Select TWO)
Answer : B, C
Option B is correct because it uses a Network Load Balancer to enable network access to the overlay IP address for the SAP NetWeaver system. A Network Load Balancer supports TCP protocol and can route traffic to targets using IP addresses. It also provides high availability and scalability for the network connection.
Option C is correct because it uses Amazon Route 53 private zone to create an A record that has the overlay IP address as a target. This allows the SAP GUI client tool to resolve the overlay IP address to the SAP NetWeaver system. It also uses the existing private connectivity to the VPC without requiring any additional components or configuration.
Option A is incorrect because it uses an Application Load Balancer, which does not support TCP protocol for the SAP NetWeaver system. It also uses an overlay IP address as a target, which is not necessary for the network access to the SAP NetWeaver system.
Option D is incorrect because it uses AWS Transit Gateway, which is not a network configuration for data transfer. It also uses an overlay IP address as a static route in the transit gateway route table, which may cause routing conflicts or errors with the existing private connectivity to the VPC.
Option E is incorrect because it uses a NAT gateway, which is not a network configuration for data transfer. It also uses an overlay IP address as a target, which may cause routing conflicts or errors with the existing private connectivity to the VPC.
https://docs.aws.amazon.com/sap/latest/sap-hana/sap-ha-overlay-ip.html
https://docs.aws.amazon.com/sap/latest/sap-netweaver/cluster-configuration-prereqs-sap-netweaver-ha.html
https://docs.aws.amazon.com/sap/latest/sap-hana/sap-oip-overlay-ip-routing-using-aws-transit-gateway.html
