Arista ACE-A1.2 Exam Questions Instant Access

Question 1

The VXLAN spec allows for two implementation types. One uses multicast. What is the other one called?

ANon-multicast replication

BBUM-Replication

CFore-end Replication

DHead-end Replication

Answer : B

Question 2

Which of the following commands will show the mac-address to VTEP table on an Arista switch?

Ashow vxlan address-table

Bshow vxlan mac-address-table

Cshow mac-address-table

Dshow vxlan summary

Answer : C

Question 3

Which command will successfully configure Ethernet5 to be 40Gbps on an Arista 7150-52 switch?

AAn Arista 7150-52 dos not support 40Gbps

BSince Ethernet 5 is a 10Gbps port, 40Gbps is not possible.

CArista(config-if-Et5)#speed forced 40gfull

DArista(config-if-Et5)#speed 40gfull

Answer : C

Question 4

If you were build a large-scale cloud-based architecture that required 100% efficient cell-based fabric, Virtual Output Queuing (VOQ), and 3.84 Tbps capacity per slot, which Arista switch series would be the correct choice?

A7010T

B7500E

C7300

D7150

Answer : B

Question 5

Which of the following are valid Event Manager triggers?

Aon-boot

Bon-schedule

Con-startup-config

Don-reload

Answer : A, C

Question 6

What Arista feature helps with the diagnosis of microbursting events?

ALANZ

BDANZ

CPANZ

DFANZ

Answer : A

Question 7

What must be active on the VMware side in order for EOS to have visibility into vNIC counters?

AvSwitches must be used.

BDistributed switches must be used.

CvSphere must be used.

DvNIC counters are not supported in VMTracer.

Answer : A

Arista Certified Engineering Associate ACE-A1.2 Exam Questions
