Avaya 76940X Exam Practice Test Instant Access

Question 1

A support engineer is upgrading a PodFX 3.1 system to ACP 4200 4.0. The system has two pairs of ServerTech PDUs.

Which statement about the PDU firmware file describes the upgrade process that the engineer needs to follow?

AIt will need to be uploaded to all 4 PDUs.

BIt will need to be uploaded to each PDU Management Web Interface.

CIt will need to be uploaded to one PDU. This PDU will then distribute the file to the remaining 3 PDUs.

DIt will need to be uploaded to Orchestrator. Orchestrator will then distribute the file to the 4 PDUs.

Answer : C

Question 2

What is the primary purpose or function of Enterprise Device Manager (EDM)?

AEDM provides an interface for administrator to monitor the health of the Nimble Storage array in a single pane and allows them to make changes to storage, protection, access, and performance configuration.

BEDM provides access to HP Proliant Servers' out-of-band management facilities. It allows for control and monitoring of HP servers.

CEDM is the device management software application for Extreme Network's VSP platforms.

DEDM provides a robust web interface which allows for monitoring of the ServerTech PDU and control of its individual power outlet.

Answer : C

Question 3

A support engineer is tasked to power down a VSP switch using the management tools available for the ACP 4200.

Which statement is true about how the engineer would accomplish this task?

ALogin to Enterprise Device Manager and use the chassis power down option.

BLogin to Servertech PDU Web Interface and use the outlet control option.

CThis can only be done if the engineer is on-site to switch off the VSP's power switch.

DThis can only be done if the engineer is on-site to remove the VSP's power cable.

Answer : A

Question 4

When deploying the vCenter update, there are certain parameters that must be used.

Which IP address should be used for the Network 1 IP Address?

AThe Localhost IP address for your datacenter subnet IP interface

BThe datacenter facing IP interface IP address and a 32 bit mask

CThe Internet facing IP interface IP address and mask

DA temporary IP, from the Management subnet, not already in use

Answer : D

Question 5

Which key consideration is critical when upgrading an application in your ACP 4200 system?

AEnsuring that the application server is able to contact http://support.avaya.com

BValidating the customer lifecycle workbook information and updating any undocumented changes that were made

CEnsuring that you have the latest VSP software installed

DChecking the IP Template for the application information and updating it with any changes made to the application

Answer : C

Question 6

A junior support engineer has been told by the support manager that summary status information for the ACP 4200 can be found in the Dashlets.

Where would the engineer go to view this information?

ALogin to Avaya Orchestrator's ACP Configuration Wizard link.

BLogin to Avaya Orchestrator's Homepage.

CLogin to the Management Server Console's Desktop.

DLogin to the Management Server Console's ACP Configuration Wizard link.

Answer : B

https://downloads.avaya.com/css/P8/documents/101054950 (13)

Question 7

A support engineer logs into the System Manager (SMGR) application on an ACP 4.0 system with the intention of checking VPFM warning messages for the VSP switch. The engineer is unable to see the VPFM link in SMGR.

What could be causing this Problem?

AThe VPFM link was removed from SMGR as part of the upgrade of the system to ACP 4.0.

BThe engineer's SMGR account has insufficient access privileges to launch VPFM.

CThe VPFM link has been renamed as Orchestrator in ACP 4.0.

DThe engineer should connect to VPFM directly and not through SMGR.

Answer : B

Avaya 76940X Avaya Converged Platform Support Exam Practice Test
