Cisco Implementing Cisco Collaboration Cloud Customer Experience v1.0 300-830 CLCCE Exam Questions

Answer : A, B

Cisco documents two Local Gateway trunking models for Webex Calling: registration-based trunks and certificate-based trunks. A registration-based trunk has the local gateway maintain SIP registration toward Webex Calling, and the signaling relationship is established through that registration. Cisco's trunk and dial plan documentation describes this model as an implicit connection based on the gateway's registration. A certificate-based trunk uses mutual TLS and certificate trust to authenticate signaling without SIP registration in the same way. These are the formal trunking choices used when integrating on-premises voice infrastructure with Webex Calling and, by extension, supporting Webex Contact Center telephony designs that use Local Gateway. DNS-based trunks are not a Cisco trunking model name in this context. PSTN trunks and enterprise trunks are generic or design descriptions, not the two Local Gateway models. For 300-830, the key is recognizing the official Webex Calling trunk model terminology. Reference: Cisco Help, Configure Local Gateway on Cisco IOS XE for Webex Calling; Configure trunks, route groups, and dial plans for Webex Calling.

Answer : B, E

The Microsoft Dynamics 365 connector provides CRM integration from the Webex Contact Center agent experience and includes configuration that allows agent workflows and screen-pop behavior to be customized around Dynamics records. Cisco's Dynamics integration guide describes installing the CRM connector, configuring the channel provider, and customizing screen-pop and workflow behavior using parameters and variables. OAuth certificate-based authentication is also part of secure connector authorization patterns used in Cisco integration workflows where an application uses certificate/private-key material instead of a simple shared secret. Agent state syncing between platforms is not the defining connector characteristic in this option set; there are synchronization features involving Webex App or CRM presence, but the connector question is focused on Dynamics connector capabilities. TLS encryption is expected for HTTPS communications but is too generic to be a distinctive answer. Read-only/read-write is not the pair Cisco emphasizes for this connector question. Reference: Cisco Help, Integrate Webex Contact Center CRM Connector for Microsoft Dynamics 365; Configure custom connector for Webex Contact Center.

Answer : A, D

Agent Desktop connectivity depends on the Webex service domains and the Contact Center service domain being reachable over HTTPS. Cisco's security and network documentation for Webex Contact Center includes domain allow-listing so the browser desktop can load scripts, APIs, authentication paths, media-related services, and Contact Center application components. The official domain patterns include Webex domains such as *.wbx.com on port 443 and Contact Center service domains such as *.ciscoccservice.com on port 443. Blocking either can prevent the desktop from loading, authenticating, or communicating with Contact Center services. The ucce.com domain is associated with Unified Contact Center Enterprise naming, not Webex Contact Center Agent Desktop. The generic amazonaws.com domain may appear in some cloud service paths, but it is not one of the two direct required domain answers here. The wxcc.com option is also not the official service domain in the documented network requirement list. Reference: Cisco Help, Set up security for Webex Contact Center; System requirements for Webex Contact Center Desktop.

Answer : B

A Webex bot conversation must preserve conversation context between incoming messages. If each incoming message starts the Webex Connect flow from the beginning, the flow is treating every webhook event as a new start event instead of waiting for the next message from the same user. The Receive node is the correct mechanism for continuing the flow after the initial webhook trigger. It should use a custom event that matches the user email, because the user identity is what links the next inbound message to the same conversation path. Matching the bot email would identify the bot endpoint, not the specific human conversation participant. Creating multiple webhooks for different steps would fragment the design and still would not preserve state cleanly. A Call Flow node is useful for modularizing logic but does not by itself wait for and correlate the user's next message. The Receive node with the user-email custom event keeps the conversation from restarting. Reference: Webex Connect Help, Receive Node and flow debugging; Webex Connect Webex Chat/Webex Engage documentation.

Answer : C, D

In Webex Contact Center, skill-based routing is built from two sides: the queue must express the skill requirement, and the agent must have the matching skill profile. Cisco's official routing and queueing documentation separates skill-based queues from non-skill queues and describes both skill criteria assigned directly to a queue and skill requirements assigned in a flow. Because the question specifically says the customer wants to use skill criteria assigned to queue functionality, the queue configuration must include the skill criteria. The agent side is handled through the skill profile assigned in the agent's settings; that profile carries the agent's skill values and proficiencies used by routing. Associating agents directly to the queue is a non-skill or agent-assignment model, and call distribution groups are for expanding team eligibility over time, not for defining agent skills. Assigning skill criteria to teams is also not the model Cisco documents. Reference: Cisco Help, Understand Routing and Queueing in Webex Contact Center; Create queues and configure routing patterns.

Answer : D

The Queue Task node is the Webex Connect node that routes a digital interaction to Webex Contact Center for distribution. Cisco's Webex Connect documentation states that Queue Task calls the Webex CC Queue Task API to queue the contact at Webex Contact Center. In an email digital-channel flow, the channel receives or creates the conversation in Webex Connect, but a live-agent handoff requires creating or queueing a task so Webex Contact Center can apply routing, queue selection, skills, and agent assignment. A Screen Pop node provides information to an agent desktop after routing has occurred; it does not queue the email. Create Conversation creates the conversation object but does not distribute the work to a contact center agent. Add Participant is used to add a participant to a conversation, not to place the email interaction into the contact center routing engine. Therefore, Queue Task is the required node for contact distribution. Reference: Webex Connect Help, Queue Task - WXCC; Webex CC Task Integration Nodes and Node Authorizations.

Answer : C

RONA must expire before voicemail answers. Cisco's voice channel guidance for Webex Contact Center and Webex Calling explains that, when agents use Webex Calling endpoints, unanswered contact center calls should be redirected back to the contact center queue before the endpoint's voicemail rule answers. If voicemail answers first, the customer call is effectively consumed by the agent's mailbox instead of being requeued for the next available agent. Setting the RONA timer shorter than the voicemail ring interval causes the contact center platform to classify the offered contact as no-answer and requeue it. Direct calls to the agent still follow the normal Webex Calling voicemail configuration, so voicemail continues to work for non-contact-center calls. Making RONA longer than voicemail is exactly the wrong direction. Two lines may help operational separation but are not required for this behavior. Disabling voicemail would break the stated requirement that direct unanswered calls roll to voicemail. Reference: Cisco Help, Set up voice channels for Webex Contact Center.
