Question 1

A client complains about systems reliability issues caused by their staff's inability to identify the root cause of failures. The client's lead administrator wants to automatically send data from HPE OneView to additional listeners in the network.

What should you configure in HPE OneView to enable the external monitoring of the managed devices?

AConfigure a scope to include the listener.

BConfigure SNMP Trap Forwarding.

CConfigure scheduled reports to export the data to the listener.

DConfigure the listener as a managed device.

Answer : B

Question 2

You are installing a HPE MSA storage system and need to connect the power cooling module (PCM).

What should you do to ensure power redundancy?

AEnsure that a physical service processor is properly connected to each PCM

BVerify that each cooling fan is cabled to a separate controller

CConnect each PCM within a shelf to a different power distribution unit (PDU)

DConnect redundant power cords from the PCM controller to independent power supplies

Answer : C

Question 3

A customer needs a solution for a rack of servers. They need connectivity for 14 HPE DL380 servers, which each have two 10-GBASE-T Ethernet ports, and 10 HPE DL360 servers, which have two 10GBASE-X SFP+ Ethernet ports.

They need switch redundancy for each server and want to connect all servers to the same switch stack. The client also needs a 400 Gb backbone connection to the data center core switch from the solution you are creating.

Which architecture meets the customer requirements?

AOne VSX stack of two Aruba 8320 48-port 1/10GBASE-X SFP+ switches with the following: 14 10GBASE-T transceivers in each switch
10 SFP+ to SFP+ DACs in each switch Two QSFP+ to Quad SFP+ adapters

BOne IRF stack of wo HPE 5945 2-Slot switches each with the following: One 24-Port SFP28 + 2-Port QSFP28 module
One 24-Port 1/10GBASE-T + 2-Port QSFP+ module 10 SFP+ to SFP+ DACs in each switch

COne IRF stack of two HPE 5945 48-port 1/10GBASE-X SFP+ switches with the following: 14 10GBASE-T transceivers in each switch
10 SFP+ to SFP+ DACs in each switch

DOne VSX stack of two Aruba 8325 48-port 1/10GBASE-X SFP+ switches with the following: 14 10GBASE-T transceivers in each switch
10 SFP+ to SFP+ DACs in each switch

Answer : C

Question 4

A customer requires a high level of network bandwidth and reliability. You are installing a pair of HPE switches that can provide redundancy with multiple connections between them for high availability and faster throughput.

Which technology should you configure on the switches to enable the capability the customer requires?

ARapid Spanning Tree Protocol (RSTP)

BVirtual Extensible Local Area Network (VxLAN)

CMultichassis Link Aggregation (MLAG)

DMultiple Spanning Tree Protocol (MSTP)

Answer : C

Question 5

You are creating a logical array on an HPE ProLiant server. The customer asks you to use drives with different capacities in a single array.

What should you explain to this customer?

AUsing drives with different capacities in a single array increases the chance of disk failure

BThe extra capacity of the larger drives will not be utilized

CThe process to create the array will fail, and the server will not boot

DThe RAID level will be set at RAID 0 automatically

Answer : B

Question 6

You are designing a server solution that requires a significant amount of memory.

Which guideline should you keep in mind when working with memory channels?

AInstall memory DIMMs of different speeds and sizes in pairs in adjoining sockets on the same memory data bus

BTo maximize performance, balance the total memory capacity across all installed processors, and load the channels similarly

COn a single-CPU server, install the first memory DIMM in channel one, the second in channel two, the third in channel three, and so on

DFor the best reliability, install DIMMs of different speeds and sizes in a single memory channel

Answer : B

Question 7

A customer needs a high level of flexibility and the most efficient use of available capacity in their MSA storage system.

How should the MSA be configured?

AAssign drives directly to servers with Fibre Channel connections on the SAN.

BCreate multiple virtual volumes in a storage pool to share resources.

CCreate virtual volumes and map them to a host group without using initiators.

DCreate a linear disk group and add dedicated spares to the group.

Answer : B
