MuleSoft MCIA-Level-1-Maintenance Exam Practice Test Instant Access

Question 1

An organization has defined a common object model in Java to mediate the communication between different Mule applications in a consistent way. A Mule application is being built to use this common object model to process responses from a SOAP API and a REST API and then write the processed results to an order management system.

The developers want Anypoint Studio to utilize these common objects to assist in creating mappings for various transformation steps in the Mule application.

What is the most idiomatic (used for its intended purpose) and performant way to utilize these common objects to map between the inbound and outbound systems in the Mule application?

AUse JAXB (XML) and Jackson (JSON) data bindings

BUse the WSS module

CUse the Java module

DUse the Transform Message component

Answer : A

Question 2

A leading bank implementing new mule API.

The purpose of API to fetch the customer account balances from the backend application and display them on the online platform the online banking platform. The online banking platform will send an array of accounts to Mule API get the account balances.

As a part of the processing the Mule API needs to insert the data into the database for auditing purposes and this process should not have any performance related implications on the account balance retrieval flow

How should this requirement be implemented to achieve better throughput?

AImplement the Async scope fetch the data from the backend application and to insert records in the Audit database

BImplement a for each scope to fetch the data from the back-end application and to insert records into the Audit database

CImplement a try-catch scope to fetch the data from the back-end application and use the Async scope to insert records into the Audit database

DImplement parallel for each scope to fetch the data from the backend application and use Async scope to insert the records into the Audit database

Answer : D

Question 3

An organization is designing a mule application to support an all or nothing transaction between serval database operations and some other connectors so that they all roll back if there is a problem with any of the connectors

Besides the database connector , what other connector can be used in the transaction.

AVM

BAnypoint MQ

CSFTP

DObjectStore

Answer : A

Correct answer is VM VM support Transactional Type. When an exception occur, The transaction rolls back to its original state for reprocessing. This feature is not supported by other connectors.

Here is additional information about Transaction management:

Question 4

When designing an upstream API and its implementation, the development team has been advised to not set timeouts when invoking downstream API. Because the downstream API has no SLA that can be relied upon. This is the only donwstream API dependency of that upstream API. Assume the downstream API runs uninterrupted without crashing. What is the impact of this advice?

AThe invocation of the downstream API will run to completion without timing out.

BAn SLA for the upstream API CANNOT be provided.

CA default timeout of 500 ms will automatically be applied by the Mule runtime in which the upstream API implementation executes.

DA load-dependent timeout of less than 1000 ms will be applied by the Mule runtime in which the downstream API implementation executes.

Answer : B

An SLA for the upstream API CANNOT be provided.

Question 5

A company is designing an integration Mule application to process orders by submitting them to a back-end system for offline processing. Each order will be received by the Mule application through an HTTP5 POST and must be acknowledged immediately.

Once acknowledged the order will be submitted to a back-end system. Orders that cannot be successfully submitted due to the rejections from the back-end system will need to be processed manually (outside the banking system).

The mule application will be deployed to a customer hosted runtime and will be able to use an existing ActiveMQ broker if needed. The ActiveMQ broker is located inside the organization's firewall. The back-end system has a track record of unreliability due to both minor network connectivity issues and longer outages.

Which combination of Mule application components and ActiveMQ queues are required to ensure automatic submission of orders to the back-end system while supporting but minimizing manual order processing?

AOne or more On Error scopes to assist calling the back-end system An Untill successful scope containing VM components for long retries A persistent dead-letter VM queue configure in Cloud hub

BAn Until Successful scope to call the back-end system One or more ActiveMQ long-retry queues One or more ActiveMQ dead-letter queues for manual processing

COne or more on-Error scopes to assist calling the back-end system one or more ActiveMQ long-retry queues A persistent dead-letter Object store configuration in the CloudHub object store service

DA batch job scope to call the back in system An Untill successful scope containing Object Store components for long retries. A dead-letter object store configured in the Mule application

Answer : B

Question 6

A Mule application is built to support a local transaction for a series of operations on a single database. The mule application has a Scatter-Gather scope that participates in the local transaction.

What is the behavior of the Scatter-Gather when running within this local transaction?

AExecution of all routes within Scatter-Gather occurs in parallel Any error that occurs inside Scatter-Gather will result in a roll back of all the database operations

BExecution of all routes within Scatter-Gather occurs sequentially Any error that occurs inside Scatter-Gather will be handled by error handler and will not result in roll back

CExecution of all routes within Scatter-Gather occurs sequentially Any error that occurs inside Scatter-Gather will result in a roll back of all the database operations

DExecution of all routes within Scatter-Gather occurs in parallel Any error that occurs inside Scatter-Gather will be handled by error handler and will not result in roll back

Answer : A

Question 7

As a part of project requirement, client will send a stream of data to mule application. Payload size can vary between 10mb to 5GB. Mule application is required to transform the data and send across multiple sftp servers. Due to the cost cuttings in the organization, mule application can only be allocated one worker with size of 0.2 vCore.

As an integration architect , which streaming strategy you would suggest to handle this scenario?

AIn-memory non repeatable stream

BFile based non-repeatable stream

CIn-memory repeatable stream

DFile based repeatable storage

Answer : D

As the question says that data needs to be sent across multiple sftp serves , we cannot use non-repeatable streams. The non-repeatable strategy disables repeatable streams, which enables you to read an input stream only once.

You cant use in memory storage because with 0.2 vcore you will get only 1 GB of heap memory. Hence application will error out for file more than 1 GB.

Hence the correct option is file base repeatable stream
