NetApp NS0-515 Exam Practice Test Instant Access

Question 1

Which data protection strategy has the most overhead capacity as a percentage of the total capacity?

ARAID 10

BRAID 6

CRAID 5

DDynamic Disk Pools (DDP)

Answer : C

Question 2

An administrator is asked to provision a 1 TB volume to hold non-critical temporary data for a seismic-analysis application. The volume requires the highest possible IOPS.

In this scenario, which configuration would satisfy this requirement?

ARAID 6 Dynamic Disk Pool with a 256 KiB segment size

BRAID 5 volume group with a 256 KiB segment size

CRAID 0 volume group with a 32 KiB segment size

DRAID 6 Dynamic Disk Pool with a 32 KiB segment size

Answer : B

Question 3

Your company has deployed an E2824 and has decided to change the host protocol from iSCSI to FC. You use the storage array profile to review the installed SFPs.

In this scenario, which set of supported data rates indicates that you are using dual-purpose SFPs?

A25 Gbps, 10 Gbps

B32 Gbps, 16 Gbps, 8 Gbps, 4 Gbps

C16 Gbps, 10 Gbps, 8 Gbps, 4 Gbps

D16 Gbps, 8 Gbps, 4 Gbps

Answer : C

Question 4

You help a customer diagnose a performance issue on an E-Series storage system. You decide to measure the amount of data that is being handled over the span of an hour.

In this scenario, what are you measuring?

AI/O alignment

Bparity

Cthroughput

DIOPS

Answer : D

Question 5

What does the CHAP secret accomplish for an E-Series system?

AiSCSI authentication

BEthernet management authentication

CFC authentication

DSAS authentication

Answer : A

Question 6

A customer is configuring an EF570 system on an internal network. Due to security concerns, the network does not have Internet access. The customer wants to regularly send standard support data to NetApp.

In this scenario, what should the customer do to accomplish this task?

AEnable AutoSupport with a set interval and with the store locally option selected, manually move the data to a server with Internet access, and then send the data to NetApp.

BOpen a support ticket with NetApp to enable AutoSupport local functionality, manually move the data to a server with Internet access, and then send the data to NetApp.

CSet up a script to initiate Collect Support Data on a set interval, manually move the data to a server with Internet access, and then send the data to NetApp.

DSet up a script to initiate Collect Support Data, remove the extra log files, manually move the data to a server with Internet access, and then send the data to NetApp.

Answer : A

Question 7

Click the Exhibit button.

Referring to the exhibit, what is the reason for the errors that are shown on port 5 on the switch of one of the fabrics?

Aprotocol errors, encoding errors, or conversion errors

Bfaulty SFPs, cables, or patch panels

Ctwisted cables, wrong plugs, or cable material

Dwrong switch configuration

Answer : A

NetApp NS0-515 NetApp Certified Implementation Engineer?SAN, E-Series Exam Practice Test
