OMG-OCUP-300 OCUP™ Exam Practice Test Instant Access

Question 1

Which UML 2.0 Superstructure package reuses the InfrastructureLibrary package?

AClasses::Core

BCompositeStructures::Core

CStructures::Kernel

DClasses::Kernel

EKernel::Classes

Answer : D

Question 2

What does the internal structure of a node consist of?

Aan elaborate arrangement of classifiers of various types

Bparts of type Nodule

Cexactly three CommuncationPath connectors

Dparts of type Node

Enodes cannot have internal structure

Answer : D

Question 3

What does the protocol conformance between two protocol state machines mean?

Aall triggers in the two protocol state machines must be the same

Bthe specific state machine must abide by the behavior of the general state machine

Cthe general state machine must abide by the behavior of the specific state machine

Dthe two protocol state machines must be the same

Ethe specific state machine must have the same number of states and transitions as the general machine

Answer : B

Question 4

What is wrong with the collaboration occurrence shown in the exhibit?

AThe <<role>> keywords are missing.

BThe <<occurrence>> keyword is missing.

CClient and Server role names should be underlined.

DThe collaboration occurrence name should be underlined.

ERole bindings should be represented by dashed lines.

Answer : E

Question 5

What is NOT possible when a classifier receives a request via one of its ports?

AA new port is created on the classifier.

BA behavior of the classifier is invoked.

CThe request does not trigger any behavior and is not forwarded.

DThe request is forwarded to a part of the classifier.

EThe port routes the request to one of a number of parts depending on the content of the request.

Answer : A

Question 6

What standard UML stereotype best captures a component's ability to represent larger-scale features of a data processing installation?

A<<specification>>

B<<subsystem>>

C<<systemModel>>

D<<realization>>

E<<installation>>

Answer : B

Question 7

What are the ways that the UML metamodel reuses the InfrastructureLibrary package? (Choose two)

Aspecializes meta-metaclasses that are defined in the InfrastructureLibrary

Bstereotypes meta-metaclasses that are defined in the InfrastructureLibrary

Cexports and generalizes metaclasses in the InfrastructureLibrary

Dimports and specializes metaclasses in the InfrastructureLibrary

Eis instantiated from meta-metaclasses that are defined in the InfrastructureLibrary

Answer : D, E

OMG Certified UML Professional OMG-OCUP-300 OCUP™ Exam Practice Test
