Question 1

A Core, Aggregation, Edge topology network is running Rapid Spanning Tree Protocol (RSTP). Two switches at the edge are legacy and run 802.1D.

To influence the convergence time of the legacy switches at the edge, where are the timers modified?

Athe route-only port on the upstream gateway

Bon the two legacy 802.1D switches at the edge

Con the Aggregation switches connected to the legacy edge switches

Don the root bridge at the core

Answer : C

Question 2

Which three objects can be assigned a Layer 3 address? (Choose three.)

AStack Interface

BVxLAN

CVirtual LAN

DVirtual Ethernet

ELoopback

FGRE tunnels

Answer : A, E, F

Question 3

Which command assigns an interface to an area?

Aip ospf area 0

Barea 0

Crouter ospf

Dip ospf cost 100

Answer : A

Question 4

In a core/edge network topology, which ports should have Root Guard enabled?

Aroute-only ports facing the WAN

Bedge ports facing the core

Ccore ports facing the edge

Dmanagement ports at the core

Answer : C

Question 5

The root bridge is connected to another switch over two independent 10Gbe links. Which link will remain in a forwarding state on both sides?

Athe link with the lowest port number on the non-root switch

Bthe link with the lowest port number on the root switch

Cthe link with the highest port number on the root switch

Dthe link with the highest port number on the non-root switch

Answer : B

Question 6

Which command must be configured at the interface level to honor Differentiated Services Code Point (DSCP)-based Class of Service (CoS) on a ICX7750?

Aqos profile

Bip dscp-remark 1

Cqos-tos map dscp-priority

Dtrust dscp

Answer : D

Question 7

Which two commands display Power over Ethernet (PoE) power budget? (Choose two.)

Ashow configuration

Bshow inline power

Cshow version

Dshow chassis

Eshow inline power detail

Answer : B, E
