VMware 5V0-42.21 Exam Practice Test Instant Access

Question 1

Which form factor can a customer use to deploy VMware SD WAN Edge?

AOracle Virtual Box

BOpen Virtualization Appliance

CDocker Container

DHyper-V Virtual Machine

Answer : B

Question 2

A network architect is designing a VMware SD-WAN architect for customer using VMware hosted VCO and VCGs, white VCEs will be deployed at the customer's branches and data centers. The network architect would like to achieve control plane redundancy.

Which action, if any, should be taken to meet this goal?

AMultiple VCGs are automatically assigned to every VCE and control plane on VCUs is always enabled, so control plane redundancy has been taken care of already

BMultiple VCFs at data centers can be contoured to function as route reflectors to achieve control plane redundancy.

CVCGs automatically assigned to a VCF. do not participate in control plane At least two dedicated Controllers should be manually assigned for each VCGs to achieve control plane redundancy.

DVCGs automatically assigned to a VCE do not participate in control plane At least two dedicated Controllers should be manually assigned for the customer to achieve control plane redundancy

Answer : B

Question 3

A technician needs to SSH to it VMware SU-WAN Virtual Edge running version 3.3.2. What is the default password?

Aadnim

BNo password required

CPassword configured in cloud_init

Dvelocloud

Answer : C

Question 4

What Is a typical use case for the deployment of a VMware SU-WAN Partner Gateway?

AProvide connectivity between multiple enterprise customers over private circuits

BGet improved flow analytics for all traffic in the SD-WAN network

CInterconnect branches/remote sites of a single enterprise customer to the internet

DProvide mite transport m a service provider backbone tor interconnecting a global customer SD-WAN branches.

Answer : D

Question 5

The VMware SD-WAN solution is comprised of Orchestrator, Gateway, and Edge. The architecture ensures separation and secure communication between the management, control, and data plane of the solution.

The management plane consists of the VMware SD-WAN Orchestrator, and the control plane is comprised of the VMware SO-WAN Gateway/ Controller. Which statement correctly describes this situation?

AVMware SD-WAN Edges/Gateways establishes a Transport Layer Security (TLS) 1 2 encrypted session to the VMware SU-WAN Orchestrator

BTo make the entire solution to work property, TCP port 443 and HOP port 500 and UDP port 4500 are required to open in the firewall rule, if Edge is deployed behind a Firewall.

CThere is impact on data plane when the Edge loses connectivity to the management plane. The operator only loses the visibility of the Edge from Orchestrator and cannot make configuration changes on the Edge until the management plane connectivity is resumed.

DTraffic between VMware SD-WAN Edges and from VMware SD-WAN Edges to VMware SD-WAN Gateways uses VMware SD-WAN Management Protocol (VCMP) tunneling over User Datagram Protocol (UDP) port 2427. secured with Internet Protocol Security (IPSec)

Answer : D

Question 6

A customer would like to use a VNF firewall on the VMware SU-WAN 600 series Edge.

Where do the Edge firewall rules of the VNF apply?

AUnderlay

BOverlay

CWAN side

DLAN side

Answer : C

Question 7

A customer is looking to have Quality of Service (QoS), resource allocations, link/path steering, and error correction applied automatically based on applications.

Which component of VMware SD-WAN helps the customer achieve this requirement?

AOverlay Flow Control

BHigh Availability Configuration

CBusiness Policy Framework

DBranch Site Topologies

Answer : C
